Parallax has made this compass IC accessible by providing Hitachi’s surface mount sensor chip with a 3 V onboard voltage regulator and resistor protection, all in a 0.3 inch wide 6-pin DIP module. This Compass Module made exclusively by Parallax is a dual-axis magnetic field sensor built around the Hitachi HM55B IC. * CD-ROM including software and documentation * Host and target source for Diagnostics, POST, and EEPROM programming One port pinned out to standard 9 pin DSUB. * 2 Enhanced CAN ports with on-board transceivers. * 2 SCI ports with on-board transceivers.

* Support for external emulator via standard JTAG header * On-board embedded JTAG emulation with USB host connection

Furthermore, the module is an excellent platform to develop, demonstrate, and run software for the TMS320F2808 controller. The kit, which provides new performance-enhancing features such as embedded IEEE 1149.1 JTAG controller with USB emulation, can be operated without additional development tools such as an emulator.

This module provides plug-and-play functionality, enabling both experienced and novice designers an easy way to get started immediately with innovative product designs. The TMS320F2808 eZdsp™ is a stand alone module that lets evaluators examine certain characteristics of the TMS320F2808 digital signal controller to determine if this DSP-based processor meets their application requirements.
